Converting a 26 roadster to a roadster pickup

Post by fordt » Mon Feb 10, 2020 2:32 pm

In the process of doing this and have come to the point where I can add the roadster’s metal floor to the frame. Since this was the original “trunk” floor and there’ll be no trunk, do I need to add the floor back with the pickup bed going over it anyway? It would seem the original metal floor would add some additional rigidity to the overall body subframe. Along this same line, did the back of the cab have a ledge or flange to attach the trunk floor to the back of the cab? Seems like with the battery cutout, one would need a way to fasten the two portions on either side of the cutout to prevent them from flopping around.....other than just rivets or screws into the cab back panel....

User avatar

DanTreace
Posts: 1025
Joined: Sun Jan 06, 2019 10:56 am
First Name: Dan
Last Name: Treace
Location: North Central FL
MTFCA Number: 4838
MTFCI Number: 115
Contact:

Re: Converting a 26 roadster to a roadster pickup

Post by DanTreace » Mon Feb 10, 2020 5:55 pm

Rob

You don't have to add the sheet metal floor unless you want too, since you are putting on the pickup bed.

The runabout body does have a metal 'return' below the tub for the metal panel to fit, it has a lip to hold that floor. The metal floor does have rim for the battery door, but you can make something do with the wood floor only to hold the door in place, a hump plate will fit your your wood bed anyway as that bed has to clear the rear crossmember.

Depending on the year of your bed, the later used a 'filler' plate on both sides to cover the gap between the runabout tub and the front panel of the bed. Early beds just had exposed area there.

rear pickup body.jpg
rear pickup body.jpg (57.4 KiB) Viewed 1196 times
DCP_1084 (600x400) (580x387).jpg
DCP_1084 (600x400) (580x387).jpg (147.1 KiB) Viewed 1196 times
rear pickup body.jpg
rear pickup body.jpg (57.4 KiB) Viewed 1196 times

When doing a '26 pickup, removed the rusted floor panel and placed the completed bed with wood floor onto the runabout subframe, works good that way too. ;)
bed hump plate under side.jpg
bed hump plate under side.jpg (68.84 KiB) Viewed 1196 times
The best way is always the simplest. The attics of the world are cluttered up with complicated failures. Henry Ford
Don’t find fault, find a remedy; anybody can complain. Henry Ford


Topic author
fordt
Posts: 55
Joined: Wed Jun 19, 2019 5:21 pm
First Name: Rob
Last Name: Trippet
Location: Comfort, TX

Re: Converting a 26 roadster to a roadster pickup

Post by fordt » Mon Feb 10, 2020 8:00 pm

Thanks! So do you think there’s any advantage to putting the metal “floor” back in for structural reasons?


Original Smith
Posts: 1191
Joined: Tue Jan 08, 2019 10:43 am
First Name: Larry
Last Name: Smith
Location: Lomita, California
MTFCA Number: 121
MTFCA Life Member: YES
MTFCI Number: 16310

Re: Converting a 26 roadster to a roadster pickup

Post by Original Smith » Mon Feb 10, 2020 9:29 pm

I don't think the roadster pickup in 1926 had a metal floor. Just stop and figure it out! Why would you put bed wood over a metal bottom?. Pretty dumb idea I'd say! What I would like to see you do is check with the owner of a '26 pickup that has a totally an original bed and has never had the wood changed to find out the original thickness. There is another post of this subject now somewhere. I wish I knew more about 1926 pickups, but I don't. I do know for a fact, the 1925 pickup wood was 13/16", not 3/4 as many believe. Let us all know what you find out.


Jeff Hood
Posts: 82
Joined: Sun Jan 06, 2019 11:25 pm
First Name: Jeff
Last Name: Hood
Location: Long Beach, CA.
MTFCA Number: 25636

Re: Converting a 26 roadster to a roadster pickup

Post by Jeff Hood » Mon Feb 10, 2020 9:30 pm

Seems like adding the floor would collect dirt and water leading to rust.


Topic author
fordt
Posts: 55
Joined: Wed Jun 19, 2019 5:21 pm
First Name: Rob
Last Name: Trippet
Location: Comfort, TX

Re: Converting a 26 roadster to a roadster pickup

Post by fordt » Mon Feb 10, 2020 10:00 pm

That’s a great point....maybe Scott C will take a look at his new PU and see if there’s any evidence of trunk floor on it. Looking at his bed picts, looks like he doesn’t have a diff hump on his....
I wonder if there’s more “converted” RPU’s out there with beds over metal floors? Seems like it might have been easier to slap a bed on a previous roadster and not take the time to drill out the riveted in trunk floor. And I imagine Ford sent a few factory RPU’s out with cabs that still had trunk attachment holes in the cab, just to save a buck or two...


Scott C.
Posts: 174
Joined: Sun Jan 06, 2019 11:44 am
First Name: Scott
Last Name: Clements
Location: Waynetown Indiana
MTFCA Number: 49592

Re: Converting a 26 roadster to a roadster pickup

Post by Scott C. » Tue Feb 11, 2020 1:15 am

At first glance, I did not see a metal floor. I will take a closer look and see if I can tell if there ever was one.

User avatar

DanTreace
Posts: 1025
Joined: Sun Jan 06, 2019 10:56 am
First Name: Dan
Last Name: Treace
Location: North Central FL
MTFCA Number: 4838
MTFCI Number: 115
Contact:

Re: Converting a 26 roadster to a roadster pickup

Post by DanTreace » Tue Feb 11, 2020 9:38 am

Unless someone can confirm factory assembled pickup didn't have a metal deck (rear floor ), then IMO, all runabout bodies came with a metal deck.

A '26 pickup that I restored had the metal deck. The metal deck sealed road grime, and it also has the battery door flange, and bump up for the rear crossmember.

The pickup bed with its wood floor slats sits above the metal deck, as its mounted on side members that bolt to the subframe. Makes it very easy to remove a turtle deck (they have no floor and rely on the metal deck) and mount a pickup bed with its wood floor for hauling stuff, easy to slide things over a wood floor out of the bed. :)


Now perhaps later '27 factory assembled might not have the metal deck, but seems odd. Although that may be the reason the later pickup beds have a forward 'filler' plate to cover the gap between the tub and the front of the bed, that would hide bare frame rails if no metal deck. Don't know, have only experience with pickup bed over the metal deck on a '26.

Note the metal deck under with flange to keep battery door in place, same as runabout only it has a wood door, the pickup bed uses a metal door, with unique molding to mimic the metal bed strips for cosmetic effect.
IMG_0428 (640x406).jpg

Scan0596 - Copy.JPG


Metal deck on runabout body, interchangeable turtle or bed easy.
IMG_9388 (2).jpg
Riveted to the bed 'filler' plate on this later bed, blocks the gap at the body tub.
The best way is always the simplest. The attics of the world are cluttered up with complicated failures. Henry Ford
Don’t find fault, find a remedy; anybody can complain. Henry Ford


Topic author
fordt
Posts: 55
Joined: Wed Jun 19, 2019 5:21 pm
First Name: Rob
Last Name: Trippet
Location: Comfort, TX

Re: Converting a 26 roadster to a roadster pickup

Post by fordt » Tue Feb 11, 2020 9:43 am

Cool! That picture of the metal stamped battery door is great! Good point about the metal deck stopping a lot of road gunk from hitting the underside of a “vulnerable” wood bed...


Scott C.
Posts: 174
Joined: Sun Jan 06, 2019 11:44 am
First Name: Scott
Last Name: Clements
Location: Waynetown Indiana
MTFCA Number: 49592

Re: Converting a 26 roadster to a roadster pickup

Post by Scott C. » Wed Feb 12, 2020 1:30 am

I do not see any sign that there was a metal floor on the 27. But, with the bed installed, it is hard to see for sure. So, I was thinking. Why would some one spend the time and effort to totally remove the metal floor and all the rivets, if it was not necessary? Back in the day, they were probably not worried about anything other than functionality and they did not have all of the handy power tools that we have today. I do think how ever, that Henry would have omitted it during assembly just save a buck, as it was not a necessary part for a pickup. The early ones probably did have the deck because they were in the design phase and probably using roadsters right off of the line. As far as it protecting the wood bed floor, that makes no sense to me because the bed extends beyond the deck leaving the rear portion of the wood exposed.


Humblej
Posts: 409
Joined: Sun Jan 06, 2019 12:23 pm
First Name: Jeff
Last Name: Humble
Location: Charlevoix, Mi
Board Member Since: 2006

Re: Converting a 26 roadster to a roadster pickup

Post by Humblej » Wed Feb 12, 2020 7:16 am

There is some great knowledge and advice provided so far and the origional photo is a great resource.
I will add a thought from a different perspective as a retired engineer. Some things are intended to be taken apart and some things are not. Something that is bolted together is a "seperable assembly" and is intended to be taken apart or upgraded, or replaced. If it is welded or riveted it is a "inseperable assembly" and is not intended to be taken off or taken apart. Using this engineerinng logic, if the floor is riveted in place it is intended to stay that way with either the turtle back or pickup bed.
Another way to think this through would be to consider what was done for the pickup bed on the previous model. The 1925 roadster pickup had the pickup bed installed over the turtleback floor.
Having said this, I would still favor any origional examples, photo evidence, drawings, and origional documentation over engineer logic or reasonable man on the street best guess.


Original Smith
Posts: 1191
Joined: Tue Jan 08, 2019 10:43 am
First Name: Larry
Last Name: Smith
Location: Lomita, California
MTFCA Number: 121
MTFCA Life Member: YES
MTFCI Number: 16310

Re: Converting a 26 roadster to a roadster pickup

Post by Original Smith » Wed Feb 12, 2020 10:50 am

Can you imagine drilling each hole for the bed strips through the metal floor? Something to think about.

User avatar

DanTreace
Posts: 1025
Joined: Sun Jan 06, 2019 10:56 am
First Name: Dan
Last Name: Treace
Location: North Central FL
MTFCA Number: 4838
MTFCI Number: 115
Contact:

Re: Converting a 26 roadster to a roadster pickup

Post by DanTreace » Wed Feb 12, 2020 2:56 pm

Larry

The '26-'27 pickup steel bed is a standalone assembly. The wood floor boards are fastened to the metal sides of the bed, and along the rear, and at the front of the metal bed. The metal strips only provide center support for the wood floor.

The carriage bolts are short and only go between each wood board, no holes to drill, and into a special 'toothed' square washer that locks into the saw kerfs on the board underside, and fastened with a square nut.

The assembly fits over the metal deck of the runabout, and it is above the deck for clearance. The side frame rails of the bed are what hold it up over the metal deck. No fasteners go into the metal deck to hold the pickup bed.

bed rear tail lamp mount web.jpg
bed rear tail lamp mount web.jpg (50.89 KiB) Viewed 725 times
Reproduction board and reproduction special washer, note the repro washers are a bit too narrow to fit well into the kerf, or else the reproduction boards are made with the saw kerf too wide apart, although the metal strips fit well into the upper kerfs. The tooth ends of the square washer should bite into the saw blade kerf, to keep the washer and board from separating or moving apart under loads, the metal bed strips fit the same way on the upper surface of each board, into matching saw kerfs. Those metal strips cover the gap between each bed board.

bed sq washer under bed web.jpg
bed sq washer under bed web.jpg (47.04 KiB) Viewed 725 times
Wood bed set for the '26-'27 pickup metal bed.
The best way is always the simplest. The attics of the world are cluttered up with complicated failures. Henry Ford
Don’t find fault, find a remedy; anybody can complain. Henry Ford


Topic author
fordt
Posts: 55
Joined: Wed Jun 19, 2019 5:21 pm
First Name: Rob
Last Name: Trippet
Location: Comfort, TX

Re: Converting a 26 roadster to a roadster pickup

Post by fordt » Wed Feb 12, 2020 4:42 pm

This is really invaluable info for me! While I’m still a few days away from putting the body subframe on the frame, some of this will no doubt become clearer when I’m looking at the same pictures you’re posting and the information I’m picking up. Figured I’d get all the stuff riveted to the frame like running board brackets, brake quadrants and a body bracket or two before the body subframe goes on and is in the way.


Original Smith
Posts: 1191
Joined: Tue Jan 08, 2019 10:43 am
First Name: Larry
Last Name: Smith
Location: Lomita, California
MTFCA Number: 121
MTFCA Life Member: YES
MTFCI Number: 16310

Re: Converting a 26 roadster to a roadster pickup

Post by Original Smith » Sat Feb 15, 2020 9:45 pm

That photo Dan posted above looks like a '25 to me. The notch in the front of the front panel for a '26 goes in much further.
