leaning left
Leaning left is not only my politics, it's also an issue with my 1915/16 runabout. The right side fenders (front and rear) measure 3" higher than the left side. It's been this way since I bought it 5 years ago and it hasn't really bothered me but I'd like to straighten it up. Any suggestions?
-
TXGOAT2
- Posts: 8484
- Joined: Sun Feb 14, 2021 10:08 pm
- First Name: Pat
- Last Name: McNallen
- * REQUIRED* Type and Year of Model Ts owned: 1926-7 roadster
- Location: Graham, Texas
- Board Member Since: 2021
Re: leaning left
Probably the springs.
-
speedytinc
- Posts: 5174
- Joined: Fri Feb 12, 2021 12:24 pm
- First Name: john
- Last Name: karvaly
- * REQUIRED* Type and Year of Model Ts owned: 14/15 wide track roadster. 23 touring, 27 roadster pickup, 20ish rajo touring
- Location: orange, ca
- Board Member Since: 2020
Re: leaning left
1) Check that the springs are correctly centered in their frame mounts & pads.
2) Look for broken leafs. Some can be hidden behind frame channels.
If the springs are in tact, but maybe weak on the driver side, turn them around.
2) Look for broken leafs. Some can be hidden behind frame channels.
If the springs are in tact, but maybe weak on the driver side, turn them around.
-
Colin Mavins
- Posts: 385
- Joined: Sun Jan 06, 2019 1:36 pm
- First Name: Colin
- Last Name: Mavins
- Location: Winnipeg Canada
Re: leaning left
My car had the same problem not as bad about an inch and a half , when I broke the crank while it was apart we flipped both springs as it had been 50 years now the car leans a little right but is level when I get in.
-
Bill Mullins
- Posts: 74
- Joined: Sun Jan 06, 2019 4:58 pm
- First Name: Bill
- Last Name: Mullins
- * REQUIRED* Type and Year of Model Ts owned: 1927 Tudor
- Location: Spokane WA
- Board Member Since: 2005
Re: leaning left
Make sure shackles and perches are not binding.
-
Mike Silbert
- Posts: 242
- Joined: Sat Feb 08, 2020 11:30 pm
- First Name: Mike
- Last Name: Silbert
- Location: Sykesville Md
- MTFCA Life Member: YES
Re: leaning left
I don't think this is your problem but, don't forget about the spring clips (the u bolts).
The early front crankcase front bearing uses 2 U bolts and the later uses one.
Having these unevenly tight or just loose will cause crooked and other problems.
The proper tension (torque) applies to ALL fasteners in a Model T so check them all while you are in the area.
Mike
The early front crankcase front bearing uses 2 U bolts and the later uses one.
Having these unevenly tight or just loose will cause crooked and other problems.
The proper tension (torque) applies to ALL fasteners in a Model T so check them all while you are in the area.
Mike
-
TRDxB2
- Posts: 6553
- Joined: Tue Jan 08, 2019 4:56 pm
- First Name: Frank
- Last Name: Brandi
- * REQUIRED* Type and Year of Model Ts owned: Speedsters (1919 w 1926 upgrades), 1926 (Ricardo Head)
- Location: Moline IL
- Board Member Since: 2018
Re: leaning left
Wondering how much higher the running board is if both front & rear right side fenders are 3" higher. The Model T 3 point suspension allows the front transverse leaf spring to angel independently of the rear. So a front spring issue wouldn't necessarily cause the rear & vs versa.Martin wrote: ↑Tue Jan 27, 2026 12:17 pmLeaning left is not only my politics, it's also an issue with my 1915/16 runabout. The right side fenders (front and rear) measure 3" higher than the left side. It's been this way since I bought it 5 years ago and it hasn't really bothered me but I'd like to straighten it up. Any suggestions?
I'd measure some other points for differences, the ends of the springs, sides of frame, to narrow down where a difference does not exist
- Attachments
-
The past is a great place and I don't want to erase it or to regret it, but I don't want to be its prisoner either.
Mick Jagger
Mick Jagger
-
jiminbartow
- Posts: 2473
- Joined: Sun Jan 06, 2019 10:55 pm
- First Name: James
- Last Name: Patrick
- * REQUIRED* Type and Year of Model Ts owned: 1926 Coupe
- Location: Bartow, FL
- Board Member Since: 2001
Re: leaning left
Very common. Especially if a former owner was heavy or obese.
