FS Ed Winfield 5H Sidedraft Racing Carburetor (SOLD)
-
ThreePedalTapDancer
Topic author - Posts: 1631
- Joined: Sun Nov 24, 2019 2:29 pm
- First Name: Ed
- Last Name: Martin
- * REQUIRED* Type and Year of Model Ts owned: 1914 Touring, 1909 Touring
- Location: Idaho
FS Ed Winfield 5H Sidedraft Racing Carburetor (SOLD)
Original Ed Winfield 5H side draft racing carburetor. The rarest of them all. Very simple carburetor. Good clean rebuildable condition, complete with barrel float. Throttle barrel nice, turns smooth in bore. Brass throttle arm will need worn oval hole on the end brazed and re-drilled back to shape for desired throttle linkage. Cast aluminum body, no pot metal. 2-11/16 between mounting holes, 1-3/8 opening. Included two float needle seats, one modified, one unmodified so the float shut-off needle can be fitted, sealed and reset.(Float needle design similar to Stromberg OF) Includes brass matching port adapter for Frontenac? 625 includes shipping.
- Attachments
-
-
-
Last edited by ThreePedalTapDancer on Sun Apr 28, 2024 2:42 am, edited 1 time in total.
-
Rajo23
- Posts: 80
- Joined: Sun Jan 06, 2019 10:30 pm
- First Name: John
- Last Name: Goertzen
- * REQUIRED* Type and Year of Model Ts owned: 1923 Touring, 1927 Runabout
- Location: Canby, OR
Re: FS Ed Winfield 5H Sidedraft Racing Carburetor
I will buy it.
How would you like to be paid?
How would you like to be paid?
