Headlight rim removal
I am trying to remove the headight rims on my 24 touring because I suspect burned out bulbs. I have only one beam on one side while the other side is neither beam. Possibly the one side with no beam could be a ground issue, however that should not be the case with the side with one beam. I have replaced the reflectors and installed new sockets and bulbs. Also have tested contacts on ends of plugs & power at both contacts. Also new rope seals to keep dust out of lights. I do have the rim tool & applying inward pressure & turning counter clockwise should remove it. Has anyone experienced this problem? Thank you!
-
- Posts: 7238
- Joined: Fri Jan 04, 2019 9:37 pm
- First Name: Steve
- Last Name: Jelf
- * REQUIRED* Type and Year of Model Ts owned: 1923 touring and a few projects
- Location: Parkerfield, Kansas
- Board Member Since: 2007
- Contact:
Re: Headlight rim removal
Has anyone experienced this problem?
Everyone has experienced this problem. Put a carpet or foam pad on the floor to catch the lens when it suddenly pops loose. Try leaning in with a hip against the rim as you turn it. I'm guessing your rim tool is the squared-C type. I made one of these: https://dauntlessgeezer.com/DG112.html
The parts dealers used to sell these. I don't know if they still do.
The inevitable often happens.
1915 Runabout
1923 Touring
1915 Runabout
1923 Touring
-
- Posts: 1957
- Joined: Sun Jan 06, 2019 12:23 pm
- First Name: Jeff
- Last Name: Humble
- * REQUIRED* Type and Year of Model Ts owned: 1926 Canadian coupe, 1924 TT C-cab, 1924 runabout
- Location: Charlevoix, Mi
- Board Member Since: 2006
Re: Headlight rim removal
It is almost impossible to get the rims off by myself. Get a helper, 4 hands will do the job. push in the rim at each rivet location and twist counterclockwise all at the same time and it will come off. But if you only push at 2 rivets at a time it isnt going to budge
Last edited by Humblej on Fri Aug 25, 2023 10:52 am, edited 1 time in total.
-
- Posts: 2814
- Joined: Sun Jan 06, 2019 5:25 pm
- First Name: George
- Last Name: House
- * REQUIRED* Type and Year of Model Ts owned: ‘10 Maxwell AA, ‘11Hupp Model 20, Two 1914 Ford runabouts, 19 centerdoor, 25 C Cab,26 roadster
- Location: Northern Caldwell County TX
- MTFCA Life Member: YES
- Board Member Since: 1999
Re: Headlight rim removal
I’ve used a small screwdriver and pried at 2 rivet locations to release the rim. If you do this carefully you won’t even scratch the paint.
A Fine is a Tax for Doing Something Wrong….A Tax is a Fine for Doing Something RIGHT
-
- Posts: 3743
- Joined: Sun Jan 06, 2019 10:53 am
- First Name: Tim
- Last Name: Wrenn
- * REQUIRED* Type and Year of Model Ts owned: '13 Touring, '26 "Overlap" Fordor
- Location: Ohio
- Board Member Since: 2019
Re: Headlight rim removal




-
- Posts: 3813
- Joined: Sun Jan 06, 2019 10:56 am
- First Name: Dan
- Last Name: Treace
- * REQUIRED* Type and Year of Model Ts owned: ‘12 open express,'23 cutoff, '27 touring
- Location: North Central FL
- Board Member Since: 2000
- Contact:
Re: Headlight rim removal
Using the rim tool is helpful IMO. Wrap rim with a rag first to give more friction contact for the rivet head recesses in the tool.
Then push, very
hard, using your hip or gut, against the tool, and at same time twist the tool, you have to compress the bucket spring against the reflector to allow the bayonet clips on the bucket to release the rivet tangs on the rim.
Then the rim is loose and can be removed.
Then push, very

Then the rim is loose and can be removed.
The best way is always the simplest. The attics of the world are cluttered up with complicated failures. Henry Ford
Don’t find fault, find a remedy; anybody can complain. Henry Ford
Don’t find fault, find a remedy; anybody can complain. Henry Ford
-
- Posts: 1119
- Joined: Sat Apr 13, 2019 6:06 pm
- First Name: Susanne
- Last Name: Rohner
- * REQUIRED* Type and Year of Model Ts owned: Late '15 touring, "Angel".
- Location: Valfabbrica, (central) Italy
- MTFCA Life Member: YES
- Board Member Since: 1999
- Contact:
Re: Headlight rim removal
Had the best luck using a GOOD headlight rim band wrench in the right hand and using my thigh to push in the RIM, then using the palm of my left hand to bump it on along until it relents. Sometimes those old and rusty rim springs can be a (deleted), also make sure you've put Kroil (or something equivalent) along the bucket to rim junction... rust and/or corrosion is not your friend.
-
- Posts: 2246
- Joined: Sun Jan 06, 2019 11:39 am
- First Name: Tim
- Last Name: Juhl
- * REQUIRED* Type and Year of Model Ts owned: 1917 Touring
- Location: Thumb of Michigan
- Board Member Since: 2018
Re: Headlight rim removal
I second the idea of using a little penetrating oil around the rim and let it sit a bit. Push in on the rim all the way around and make sure you can move it in a bit. Then apply pressure from hands, knees, gut, whatever and turn. All the other advice is good - I might add that a large strap wrench will sometimes do the job as well. The metal is thin so protect it, whatever tool you use.
1917 Touring
1946 Aeronca Champ
1952 Willys M38a1 Jeep (sold 2023)
1953 Ford Jubilee Tractor
1946 Aeronca Champ
1952 Willys M38a1 Jeep (sold 2023)
1953 Ford Jubilee Tractor
-
- Posts: 5019
- Joined: Tue Jan 08, 2019 7:31 pm
- First Name: Dan
- Last Name: Hatch
- Location: Alabama
Re: Headlight rim removal
These were made by a couple of our forum members a few years back. Work great!!!!
-
- Posts: 5174
- Joined: Sun Jan 06, 2019 12:18 pm
- First Name: Steve
- Last Name: Tomaso
- * REQUIRED* Type and Year of Model Ts owned: 1914 Touring, 1919 Centerdoor, 1924 TT C-Cab Express, 1925 Racer
- Location: Longbranch, WA
- Board Member Since: 2001
Re: Headlight rim removal
You didn't mention wether or not the rims are original or repros - I've seen repros that had too long of rivets used and can cause a major headache for both installation & removal. I use the "rubber mat on the floor" procedure myself.
-
- Posts: 4434
- Joined: Sun Jan 06, 2019 8:00 pm
- First Name: John
- Last Name: Kuehn
- * REQUIRED* Type and Year of Model Ts owned: 19 Roadster, 21 Touring, 24 Coupe
- Location: Texas
Re: Headlight rim removal
So what did the Ford dealerships use to remove the rims? Probably like was mentioned using four hands.
The trick is getting the rim pushed in EVENLY. If that doesn’t happen you won’t move it. WD-40 helps too.
The trick is getting the rim pushed in EVENLY. If that doesn’t happen you won’t move it. WD-40 helps too.
-
- Posts: 5019
- Joined: Tue Jan 08, 2019 7:31 pm
- First Name: Dan
- Last Name: Hatch
- Location: Alabama
Re: Headlight rim removal
Look in the Service Bulletins. You will find the tool like I posted and later the tool Dan T showed.
Also the Ford Owner and Dealer magazine had some great ideas for how to things on the T.
Remember, someone 100 years ago was trying to figure out how to do this stuff too. And with a lot less than what we have now. Dan
Also the Ford Owner and Dealer magazine had some great ideas for how to things on the T.
Remember, someone 100 years ago was trying to figure out how to do this stuff too. And with a lot less than what we have now. Dan
-
- Posts: 7238
- Joined: Fri Jan 04, 2019 9:37 pm
- First Name: Steve
- Last Name: Jelf
- * REQUIRED* Type and Year of Model Ts owned: 1923 touring and a few projects
- Location: Parkerfield, Kansas
- Board Member Since: 2007
- Contact:
Re: Headlight rim removal
Checking Lang's catalogue, I see only the tool Dan Treece posted. Preferring the other type, I made mine hinged so it comes apart to fit in my under-seat tool box. Used properly it gets a good, solid grip on all four rivets.
The inevitable often happens.
1915 Runabout
1923 Touring
1915 Runabout
1923 Touring
-
- Posts: 755
- Joined: Tue Jan 08, 2019 12:39 am
- First Name: Dan
- Last Name: S
- * REQUIRED* Type and Year of Model Ts owned: '23 and '26
- Location: Taxachusetts
- Board Member Since: 2015
Re: Headlight rim removal
You need at least 2 guys and 4 hands, and someone to be present to heckle...
Take the stubborn headlight off the car....
Place the headlight bucket down, lens up in a folded and fluffed up moving blanket. 1rst guy pushes down on the headlight bezel rim and turns counter clockwise. 2nd guy "tries" to keep the headlight bucket from turning by holding bucket and bucket mount arm.
If this fails, turn the headlight over and go lens down. Repeat procedure as above. But be leary of breaking the glass face down.
Gentle taps on the bezel at the bezel pins counter clockwise may help too.
Good luck and let me know how it goes...
-Dan
Take the stubborn headlight off the car....
Place the headlight bucket down, lens up in a folded and fluffed up moving blanket. 1rst guy pushes down on the headlight bezel rim and turns counter clockwise. 2nd guy "tries" to keep the headlight bucket from turning by holding bucket and bucket mount arm.
If this fails, turn the headlight over and go lens down. Repeat procedure as above. But be leary of breaking the glass face down.
Gentle taps on the bezel at the bezel pins counter clockwise may help too.
Good luck and let me know how it goes...
-Dan
________________
**FATE**
---------------------------
**FATE**
---------------------------
-
- Posts: 14
- Joined: Sat Mar 30, 2019 3:28 pm
- First Name: Mark
- Last Name: Foster
- * REQUIRED* Type and Year of Model Ts owned: 1926 Coupe
- Location: IL
Re: Headlight rim removal
Harvey Bergstrom
"I have replaced the reflectors and installed new sockets and bulbs. Also new rope seals to keep dust out of lights."
i'm confused. How did you replace the reflectors, sockets, and bulbs, with the lenses in place?
"I have replaced the reflectors and installed new sockets and bulbs. Also new rope seals to keep dust out of lights."
i'm confused. How did you replace the reflectors, sockets, and bulbs, with the lenses in place?
-
- Posts: 751
- Joined: Mon Jan 07, 2019 7:40 am
- First Name: CHARLIE
- Last Name: BRANCA
- * REQUIRED* Type and Year of Model Ts owned: "27 Tudor / "23 Touring
- Location: Brick N.J.
- Board Member Since: 2010
Re: Headlight rim removal
I use something you probably don’t have. It’s a strap type filter remover. This is without a doubt the best tool to use on stubborn headlamp rims. Grips evenly and works like a charm. I usually put a rag under the metal section. The free end of the belt slips into a slot that’s under the square drive hole and cranks it tight. The more it tightens the harder it cranks the rim.
Forget everything you thought you knew.
-
- Posts: 39
- Joined: Wed Jan 09, 2019 2:48 pm
- First Name: Bob
- Last Name: Solak
- * REQUIRED* Type and Year of Model Ts owned: None
- Location: Chicago Area
- Board Member Since: 2019
Re: Headlight rim removal
I haven't done a lot of headlights, but here was my very simple method.
Remove the headlights from the car.
Place a neoprene mat on the floor (I used one of those mats you use to protect your fenders while leaning into the engine bay of your muscle car).
Put the headlight face down on the mat.
Use your body weight to push down on the back of the headlight housing while you twist it.
The mat grips the rim and poof! off it comes.
Remove the headlights from the car.
Place a neoprene mat on the floor (I used one of those mats you use to protect your fenders while leaning into the engine bay of your muscle car).
Put the headlight face down on the mat.
Use your body weight to push down on the back of the headlight housing while you twist it.
The mat grips the rim and poof! off it comes.
-
- Posts: 755
- Joined: Tue Jan 08, 2019 12:39 am
- First Name: Dan
- Last Name: S
- * REQUIRED* Type and Year of Model Ts owned: '23 and '26
- Location: Taxachusetts
- Board Member Since: 2015
Re: Headlight rim removal
My stated method with a neoprene mat substituted out for the moving blanket is killer! The neoprene mat may negate the need for the 2nd guy for help. Good idea!!
________________
**FATE**
---------------------------
**FATE**
---------------------------
-
- Posts: 1553
- Joined: Sun Jan 06, 2019 12:28 pm
- First Name: Duane
- Last Name: Cooley
- * REQUIRED* Type and Year of Model Ts owned: 18 Runabout, 24 Runabout for 20yrs, 25 TT, late Center Door project, open express pickup
- Location: central MN
- Board Member Since: 2015
Re: Headlight rim removal
With my old clunkers, I tap the rim with a soft rubber mallet to be certain it isn't rusted to the bucket. Or at least negotiable.
Set the lamp (lens down) on a tall vinyl covered stool, PUSH and twist it unlocked.
I like! I bet a little WD or your favorite spray would help a bunch!
Ooh, a rubber mat. Yeah! If it isn't on the floor.

Set the lamp (lens down) on a tall vinyl covered stool, PUSH and twist it unlocked.
I like! I bet a little WD or your favorite spray would help a bunch!
Ooh, a rubber mat. Yeah! If it isn't on the floor.


Since I lost my mind mind, I feel more liberated
-
Topic author - Posts: 122
- Joined: Tue Dec 27, 2022 10:12 pm
- First Name: Harvey
- Last Name: Bergstrom
- * REQUIRED* Type and Year of Model Ts owned: 1924 Touring
- Location: Cayuga ND
Re: Headlight rim removal
The buckets have been restored so they were sanded and repainted and rims are new ones which went on relatively easily.
I like Dan Hatch’s post on a great homemade tool
that surpasses the ones that the venders sell. I have one of those. I just need two more hands and I will be able to get the job done. Thank you all for the great thoughts!
I like Dan Hatch’s post on a great homemade tool
that surpasses the ones that the venders sell. I have one of those. I just need two more hands and I will be able to get the job done. Thank you all for the great thoughts!
-
- Posts: 5370
- Joined: Sat Jan 05, 2019 1:57 pm
- First Name: Mark
- Last Name: Gregush
- * REQUIRED* Type and Year of Model Ts owned: 1925 cutdown PU, 1948 F2 Ford flat head 6 pickup 3 speed
- Location: Portland Or
- Board Member Since: 1999
Re: Headlight rim removal
This is how I have been doing it for years if they are being stubborn, I use a piece of carpet. Taking them off also is a good time to clean the ground connecting.Bob Solak wrote: ↑Fri Aug 25, 2023 5:44 pmI haven't done a lot of headlights, but here was my very simple method.
Remove the headlights from the car.
Place a neoprene mat on the floor (I used one of those mats you use to protect your fenders while leaning into the engine bay of your muscle car).
Put the headlight face down on the mat.
Use your body weight to push down on the back of the headlight housing while you twist it.
The mat grips the rim and poof! off it comes.
I know the voices aren't real but damn they have some good ideas!
1925 Cut down pickup
1948 Ford F2 pickup

1925 Cut down pickup
1948 Ford F2 pickup
-
- Posts: 5174
- Joined: Sun Jan 06, 2019 12:18 pm
- First Name: Steve
- Last Name: Tomaso
- * REQUIRED* Type and Year of Model Ts owned: 1914 Touring, 1919 Centerdoor, 1924 TT C-Cab Express, 1925 Racer
- Location: Longbranch, WA
- Board Member Since: 2001
Re: Headlight rim removal
If those are new rims, chances are the rivets are a bit too long thus preventing the removal. The tool that surrounds the rim is the best second to placing the headlight on a rubber mat & using your body weight. You might still have a devil of a time if the rivets are too long and it might involve some damage to your freshly restored bucket !
-
- Posts: 755
- Joined: Tue Jan 08, 2019 12:39 am
- First Name: Dan
- Last Name: S
- * REQUIRED* Type and Year of Model Ts owned: '23 and '26
- Location: Taxachusetts
- Board Member Since: 2015
Re: Headlight rim removal
I was blasting down the road at 35 mph when the bezel popped off, and glass shattered everywhere. The bezel ring rolled down an embankment from the road. I got my bezel back from a swamp...
I've since bent the half moon tabs in, and the headlight glass lens now stays secure. Aftermarket replacement bucket???
________________
**FATE**
---------------------------
**FATE**
---------------------------
-
- Posts: 69
- Joined: Tue Feb 26, 2019 10:28 am
- First Name: Richard
- Last Name: Carlson
- * REQUIRED* Type and Year of Model Ts owned: 1922 Center Door 1923 Touring
- Location: Niwot, Colorado
Re: Headlight rim removal
I had trouble getting the rim on my bucket. I got this strap wrench at Home Depot, Husky brand. Super soft, I just got the car painted. On and off with just a pop. It has a long strap, 34 or so inches. I think it was $25 or so.


Rich


Rich
Rich in Colorado
1922 Model T Center Door
1923 Model T Touring
1928 Model A Tudor
1956 Ford Thunderbird
1966 Ford F250 Camper Special
1922 Model T Center Door
1923 Model T Touring
1928 Model A Tudor
1956 Ford Thunderbird
1966 Ford F250 Camper Special
-
- Posts: 94
- Joined: Sun Jan 06, 2019 2:11 pm
- First Name: Craig
- Last Name: Vechorik
- * REQUIRED* Type and Year of Model Ts owned: 1915 Touring, 1922 coupe
- Location: Stugis, Mississippi
Re: Headlight rim removal
I made mine out of wood. The blocks catch each rivet. You simply push and hold some pressure on the base, and twist it, and it releases the rim on my 1915 every time, with no scratches or damage.
"If a fly can, a flywheel"

-
- Posts: 361
- Joined: Mon Jan 07, 2019 9:09 am
- First Name: John
- Last Name: Zibell
- * REQUIRED* Type and Year of Model Ts owned: 1926 Tudor
- Location: Huntsville, AL
Re: Headlight rim removal
Yes they work great but a bear to make. Time and materials made making many for sale not profitable for what people would pay for one. We made a few and just gave them away to friends. You were one of the lucky ones!
1926 Tudor
